SHI-24 Air Oxygen Blender

This is a type of medical equipment used by healthcare professionals to perform rescue interventions using different concentrations of oxygen. It is particularly suitable for neonates, especially premature infants, in the treatment of oxygen-induced damage and complications such as:

• Retinopathy of Prematurity (ROP)

• Chronic Lung Disease (CLD)

These conditions can occur due to prolonged exposure to high-flow and high-concentration oxygen. The product complies with the requirements of the medical “Guide”.

It is essential to:

• Use a device that mixes air and oxygen

• Strictly follow the indications and methods of oxygen use

• Monitor and adjust the oxygen concentration in real-time according to the patient’s condition

• Avoid excessive fluctuations in oxygen levels

• Used in applications requiring precise oxygen concentration control, such as:

  • Hood

  • Nasal catheter

  • Incubator

  • Infant resuscitator

  • Heart-lung machine

• Configures different oxygen concentrations by adjusting the oxygen-to-air ratio

• Surface treated with anodic oxidation for enhanced durability

• Equipped with:

  • A regulating valve to adjust oxygen concentration

  • A pressure stabilizing device to maintain constant pressure output

• Independent control of both oxygen concentration and flow rate

• Double output port structure, allowing gas supply to one or multiple patients simultaneously

• Integrated differential pressure alarm system

  • When triggered, the safety valve activates automatically

  • Continues producing mixed gas to ensure patient safety

• Model: SHI-26

• Oxygen concentration adjustment: 21% to 100%

• Flow rate options:

  • 0.1 LPM ~ 1.0 LPM (dual output)

  • 0.1 LPM ~ 10 LPM
